Motores eléctricos

La gama de productos igus® incluye motores paso a paso en varios tamaños ampliables con encoders y frenos; motores de corriente continua económicos, silenciosos y que pueden funcionar a través de una batería o una fuente de alimentación simple, y motores EC para movimientos rápidos y potentes. También cuenta con reductoras que reducen la velocidad de salida y, por lo tanto, aumentan el par de torsión disponible.
Entre otras aplicaciones, los motores se utilizan en tecnología de empaque e inspección, por ejemplo para el recorrido de sensores y cámaras, y en el sector alimentario, en exteriores y áreas expuestas a salpicaduras y agua pulverizada.


Número de productos: 88

drylin® E lead screw stepper motor, stranded wires with JST connector and encoder, NEMA17

  • Installation size: NEMA17/flange dimension 42mm
  • Protection class: IP40
  • Holding torque: 0.50Nm
  • Nominal current: 1.80A
  • Motor connections: stranded wires with JST connector, encoder with JST connector

drylin® E lead screw stepper motor, stranded wires with JST connector and encoder, NEMA23

  • Installation size: NEMA23/flange dimension 56mm
  • Protection class: IP40
  • Holding torque: 2.00Nm
  • Nominal current: 4.20A
  • Motor connections: stranded wires with JST connector, encoder with JST connector

drylin® E lead screw stepper motor, stranded wires with JST connector and encoder, NEMA24

  • Installation size: NEMA24/flange dimension 60mm
  • Protection class: IP40
  • Holding torque: 3.50Nm
  • Nominal current: 4.20A
  • Motor connections: stranded wires with JST connector, encoder with JST connector

drylin® E stepper motor, stranded wires with Molex connector and encoder, NEMA34

  • Installation size: NEMA 34/flange dimension 86mm
  • Protection class: IP40
  • Holding torque: 5.90Nm
  • Nominal current: 6.40A
  • Motor connections: stranded wires with Molex connector, encoder with JST connector
Nuevo

drylin® E EC/BLDC motor with stranded wires, Hall, encoder and brake, NEMA23

  • Installation size: NEMA23/flange dimension 56mm
  • Protection class: IP40
  • Rated torque: 0.60Nm
  • Nominal voltage: 48V DC
  • Motor connections: stranded wires, encoder with stranded wire, brake with stranded wire
  • Brake voltage: 24V
  • Integrated brake for vertical loads
Nuevo

drylin® E EC/BLDC motor with stranded wires, Hall, encoder and brake, NEMA24

  • Installation size: NEMA24/flange dimension 60mm
  • Protection class: IP40
  • Rated torque: 0.80Nm
  • Nominal voltage: 48V DC
  • Motor connections: stranded wires, encoder with stranded wire, brake with stranded wire
  • Brake voltage: 24V
  • Integrated brake for vertical loads
Nuevo

drylin® E EC/BLDC motor with stranded wires, Hall, encoder and brake, NEMA34

  • Installation size: NEMA34/flange dimension 86mm
  • Protection class: IP40
  • Rated torque: 1.00Nm
  • Nominal voltage: 48V DC
  • Motor connections: stranded wires, encoder with stranded wire, brake with stranded wire
  • Brake voltage: 24V
  • Integrated brake for vertical loads
Nuevo

drylin® D7-(X) stepper motor driver

  • Fits 28-42mm motor flange size (NEMA11-17)
  • Up to 3A peak current
  • 5-24V control & 24-48V load voltage
  • Operating Mode 1: Clock/Direction
  • Operating Mode 2: D7 & D7-1: Jog Mode D7-2 & D7-3: Loop Mode
  • Smooth running & auto-tuning
desde / de 105.33 USD/Uni.
Ir a la página de producto
Nuevo

drylin® E EC/BLDC motor with stranded wires, Hall, encoder and brake, NEMA17

  • Installation size: NEMA17/flange dimension 42mm
  • Protection class: IP40
  • Rated torque: 0.30Nm
  • Nominal voltage: 48V DC
  • Motor connections: stranded wires, encoder with stranded wire, brake with stranded wire
  • Brake voltage: 24V
  • Integrated brake for vertical loads
Nuevo

drylin® D8-(X) stepper motor driver

  • Fits 56-60mm motor flange size (NEMA23-24)
  • Up to 5.5A peak current
  • 5-24V control & 24-48V load voltage
  • Operating Mode 1: Clock/Direction
  • Operating Mode 2: D7 & D7-1: Jog Mode D7-2 & D7-3: Loop Mode
  • Quiet running & auto-tuning
Nuevo

drylin® D9-(X) stepper motor driver

  • Fits 86mm motor flange size (NEMA34)
  • Up to 9.8A peak current
  • 5-24V control & 24-48V load voltage
  • Operating Mode 1: Clock/Direction
  • Operating Mode 2: D7 & D7-1: Jog Mode D7-2 & D7-3: Loop Mode
  • Quiet running & auto tuning

drylin® D1 motor control system for stepper, DC and EC/BLDC motors

  • A wide range of automation tasks by simple parameterisation, no programming necessary
  • For single axes, line, flat, linear and room linear robots and delta robots
  • No software installation or app required
  • Use with PC, tablet or smart phone
  • Stepper (ST), DC and EC/BLDC motors with up to 21A peak currents and 48V
  • Digital inputs/outputs, analogue inputs, CANopen, ModbusTCP (CANopen Gateway) for connection to master control systems such as Siemens or Beckhoff

    TEST BEFORE INVEST - Try out the motor control system with the online simulation here
desde / de 486.00 USD/Uni.
Ir a la página de producto

drylin® D2 motor control system for stepper, DC and EC/BLDC motors

  • A wide range of automation tasks by simple parameterisation, no programming necessary
  • For single axes, line, flat, linear and room linear robots and delta robots
  • No software installation or app required
  • Use with PC, tablet or smart phone
  • Stepper (ST), DC and EC/BLDC motors with up to 21A peak currents and 48V
  • Digital inputs/outputs, analogue inputs, CANopen, ModbusTCP (CANopen Gateway) for connection to master control systems such as Siemens or Beckhoff
The drylin® D1 motor control and the D2 are identical except for the housing.

drylin® D3 for direct current motors

  • Simple automation directly using the control system without software and/or PC
  • Operation with limit switch or via power consumption
  • Left/right operation and speed control directly on the housing
  • Option for external switches/joysticks
  • Various modes of operation, such as tip operation and start to finish (semi-automatic)
  • Various adjustable acceleration ramps
  • Power supply via 24V/2.5A

    All relevant documents for dryve D3 can be found in the downloads.
desde / de 170.64 USD/Uni.
Ir a la página de producto

drylin® D3-LM motor control system for DC motors with loop mode

  • Same dimensions as the standard D3
  • Extended functions for "Micro Automation"
  • Individually preprogrammed pendulum movements
  • Individually preprogrammed pause times between movements
